Description
TECHNICAL PARAMETER
| Parameter | Value |
|---|---|
| Model | M1200 |
| Wheelbase | **1230mm** |
| Weight of Drone (Without Battery) | 5.14kg |
| Weight of Drone (With Battery) | 13.5kg |
| Weight of Battery | 8.36kg (ARES 6S 22AH Battery or ARES 6S 27AH Battery * 4PCS) |
| Max Take-off Weight | **18.5kg** |
| Maximum Ascent Speed | 5m/s |
| Maximum Descending Speed | 3m/s |
| Maximum Horizontal Flight Speed | 15m/s |
| GPS Hover Accuracy | Vertical: **±0.5m**; Horizontal: **±2.5m** |
| Hover Time | 2kg ≥ 70mins; 5kg ≥ 65mins (**6S 27ah batteries**) |
| Maximum Tolerable Wind Speed | **13m/s** |
| Working Temperature | -15℃~50℃ |
| Propulsion System | T-MOTOR |
| Recommended Control System | PIXHAWK |
| Dimensions Folded | 585mm*585mm*570mm |
| Dimensions (Unfolded) | 990mm*1005mm*570mm |
| Packing Size | 700mm*700mm*370mm |
| Shipping Weight | 11.6kg |
